FEATURES

HBFB-features

  • Volumetric design in high durable IC rated steel housing
  • Acrylic diffuser for glare-free optimal light distribution
  • Optional factory installed emergency battery and occupancy sensor
  • Easy selectable CCT with an inbuilt DIP switch. ANSI 3500K, 4000K or 5000K CCT
  • Calculated lumen maintenance >122,000 hours as per IESNA TM-21-11
  • White finish

ELECTRICAL

  • 2×2 available in Medium (20W/25W/30W)& High (30W/35W/40W) level models
  • 2×4 available in Medium (25W/30W/34W)& High (34W/38W/45W) level models
  • Power Factor >0.90
  • Total Harmonic Distortion ≤20%
  • 2kV surge protection standard.
  • 0-10V dimming standard
  • Rated ambient operating temperature -20°C (-4°F) to 50°C (122°F)
